KOBELCO系列(無油式)
KOBELCO系列(無油式)
KOBELCO系列(無油式)
氣冷式:Air-Cooled Models(Compressor only)
Item \ Model ALE45A-5/6 ALE55A-5/6 ALE65A-5/6 ALE75CA-5/6 ALE75A-5/6 ALE90A-5/6 ALE100A-5/6
Frequency Hz 50 / 60
Discharge air volume m3/min 8.8/8.9 6.8/6.8 10.2/10.2 11.8/11.7 12.8/12.8 15.8/15.7 17.0/17.1
Suction condition pressure Atmospheric pressure
0~45
Discharge condition Pressure(gaug pressure) MPa 0.69
Compressor shaft input power
kW
42.9/43.1 54.9/55.5 63.9/64.2 76.1/75.9 75.8/75.7 91.7/91.0 101.5/102.2
Compressor motor Nominal output
kW
45.0 55.0 65.0 75.0 75.0 90.0 100.0
Voltage V 200/200.200[380.400.415/400.440]
Starting system Star Delta
Specification 2-pole totally enclosed fan-cooled(air cooled). insulation class F. rated for conditions use
Drive system Step-up gear
Discharge pipe diameter A JIS10k-40A RF
Cooling fan motor output kW 22 3.0
Initial lubricant charge L 30 50
Nominal dimensions (WxDxH) mm 1830x1400x1783 2010x1500x2160
Nominal weight kg 1790 1850 1900 1940 2590 2810 2810
Noise [at front] dB(A) 66 78 69 70 67 68 69
Oil pump output kW 1.5 2.2
氣冷式(高壓):Air-Cooled Models(Compressor only)
Item \ Model ALE45CA-5/6H ALE55A-5/6 ALE65A-5/6 ALE75CA-5/6 ALE75A-5/6
Frequency Hz 50/60
Discharge air volume m3/min 5.4/5.5 6.8/6.8 8.7/8.8 10.1/10.2 12.8/12.8
Suction condition pressure Atmospheric pressure
0~45
Discharge condition Pressure(gaug pressure) MPa 0.88
Compressor shaft input power
kW
40.6 / 40.8 49.4 / 49.5 62.7 / 63.4 72.4 / 72.8 87.9 / 87.7
Compressor motor Nominal output
kW
45.0 55.0 65.0 75.0 90.0
Voltage V 200/200.200[380.400.415/400.440]
Starting system Star Delta
Specification 2-pole totally enclosed fan-cooled(air cooled). insulation class F. rated for conditions use
Drive system Step-up gear
Discharge pipe diameter A JIS10k-40A RF JIS10k-50A RF
Cooling fan motor output kW 22 3.0
Initial lubricant charge L 30 50
Nominal dimensions (WxDxH) mm 1830x1400x1783 2010x1500x2160
Nominal weight kg 1790 1850 1900 1940 2810
Noise [at front] dB(A) 69 70 71 72 70
Oil pump output kW 1.5 2.2



Air-Cooled Models(with integrated dryer)
Item \ Model ALE45AD-5/6 ALE55AD-5/6 ALE45AD-5/6H ALE55AD-5/6H ALE65AD-5/6 H
Frequency Hz 50/60
Discharge air volume m3/min 8.8/8.9 6.8/6.8 8.8/8.9 6.8/6.8 8.7/8.8
Suction condition pressure Atmospheric pressure
0~45
Discharge condition Pressure(gaug pressure)
MPa
0.69 0.88
Compressor shaft input power
kW
42.9/43.1 54.9/55.5 40.6/40.8 49.4/49.5 62.7/63.4
Compressor motor Nominal output
kW
45.0 55.0 45.0 55.0 65.0
Voltage V 200/200.200[380.400.415/400.440]
Starting system Star Delta
Specification 2-pole totally enclosed fan-cooled(air cooled). insulation class F. rated for conditions use
Drive system Step-up gear
Discharge pipe diameter A JIS10k-40A RF
Cooling fan motor output kW 22
Dryer Pressure dew point ℃ Below 10 at discharge pressure
Input kW 3.7/4.2
Coolant type/method R22,Capillary tube
Initial lubricant charge L 30
Nominal dimensions (WxDxH) mm 2385x1400x1783
Nominal weight kg 1790 1850 1940 2000 2050
Noise [at front] dB(A) 67 68 69 70 71
Oil pump output kW 1.5

氣冷式:

  • ALE45AD-5/6   ALE55AD-5/6

氣冷式(高壓):

  • ALE45AD-5/6H  ALE55AD-5/6H  ALE65AD-5/6H
